Two-group espresso machine
two-group-espresso-machine
dresses furniture:espresso-machine
— and nothing else. Appearance is invisible to the drawing set, so adding this changes no
plan, no section and no elevation.
- 10of 500 meshes
- 4slots
- 1finish
Drag to orbit · scroll to zoom
$frame
$surface
$accent
$hardware
This definition leaves
$frame and $surface and $accent and $hardware
open, and a look line fills them. Every combination is one body — same
geometry, same selector, same sheets — so the block below rewrites itself as you pick.
Only materials are slottable: a size would have to agree with the plan, so it stays on
the entity.
Generated views
The body and its drawing evidence
The A-101 panel is the built-in plan symbol at its default envelope, not
a top-down image of this lookdef. The deterministic renders check the
body's footprint, structure and depth. Geometry, material and the
selected finish stay unchanged.
Paste this
Every part: the 3 materialdefs the body resolves to, then the definition. Copying the lookdef alone still compiles and still validates — it just renders grey.
{"t":"materialdef","id":"pack-retail-charcoal","of":"painted-metal","value":20,"accent":"#343536","body":{"metalness":0.38}}
{"t":"materialdef","id":"pack-retail-chrome","of":"chrome","value":72,"accent":"#bfc4c7","body":{"metalness":0.82}}
{"t":"materialdef","id":"pack-retail-white","of":"paint","value":92,"accent":"#f2f1ec","body":{"roughness":0.38}}
{"t":"lookdef","id":"two-group-espresso-machine","name":"Two-group espresso machine","for":"furniture:espresso-machine","desc":"Compact two-group espresso machine with raised cupshelf, portafilters and steam wand.","slots":{"frame":"pack-retail-chrome","surface":"pack-retail-charcoal","accent":"pack-retail-white","hardware":"pack-retail-chrome"},"note":"Natural box is 0.6 × 0.5 × 0.55; the raised rear body, two group heads and projecting portafilters make the front readable at catalogue size.","body":{"type":"Group","children":[{"type":"Mesh","material":"$surface","geometry":{"type":"RoundedBoxGeometry","width":0.6,"height":0.3,"depth":0.5,"radius":0.055,"segments":4},"position":[0,0.26,0]},{"type":"Mesh","material":"$frame","geometry":{"type":"RoundedBoxGeometry","width":0.56,"height":0.16,"depth":0.42,"radius":0.045,"segments":4},"position":[0,0.39,-0.03]},{"type":"Mesh","material":"$accent","geometry":{"type":"RoundedBoxGeometry","width":0.52,"height":0.04,"depth":0.36,"radius":0.018,"segments":3},"position":[0,0.48,-0.02]},{"type":"Mesh","material":"$hardware","geometry":{"type":"CylinderGeometry","radiusTop":0.055,"radiusBottom":0.055,"height":0.055,"radialSegments":20},"position":[-0.15,0.3,0.265],"rotation":[1.5708,0,0]},{"type":"Mesh","material":"$hardware","geometry":{"type":"CylinderGeometry","radiusTop":0.055,"radiusBottom":0.055,"height":0.055,"radialSegments":20},"position":[0.15,0.3,0.265],"rotation":[1.5708,0,0]},{"type":"Mesh","material":"$surface","geometry":{"type":"TubeGeometry","path":[[-0.15,0.3,0.29],[-0.08,0.27,0.35],[0.02,0.25,0.38]],"radius":0.018,"radialSegments":10,"tubularSegments":18}},{"type":"Mesh","material":"$surface","geometry":{"type":"TubeGeometry","path":[[0.15,0.3,0.29],[0.22,0.27,0.35],[0.29,0.25,0.38]],"radius":0.018,"radialSegments":10,"tubularSegments":18}},{"type":"Mesh","material":"$hardware","geometry":{"type":"TubeGeometry","path":[[-0.25,0.38,0.22],[-0.28,0.18,0.3],[-0.27,0.08,0.32]],"radius":0.012,"radialSegments":10,"tubularSegments":18,"curve":"spline"}},{"type":"Mesh","material":"$hardware","geometry":{"type":"RoundedBoxGeometry","width":0.48,"height":0.03,"depth":0.24,"radius":0.012,"segments":3},"position":[0,0.08,0.12]},{"type":"bimtex:Run","count":5,"from":[-0.2,0,0],"to":[0.2,0,0],"children":[{"type":"Mesh","material":"$surface","geometry":{"type":"RoundedBoxGeometry","width":0.025,"height":0.012,"depth":0.22,"radius":0.004,"segments":3},"position":[0,0.1,0.12]}]}]},"preview":{"projection":"perspective","azimuth":38,"elevation":22,"fov":34,"margin":1.04}}Or take the whole pack, which brings every entry and every material at once:
cat packs/retail.ndjson model.ndjson > dressed.ndjson
