Folded zinc parapet coping
folded-zinc-parapet-coping
dresses asset:parapet-coping
— and nothing else. Appearance is invisible to the drawing set, so adding this changes no
plan, no section and no elevation.
Used in examplesHouse Exterior Elements
- 3of 500 meshes
- 2slots
- 1finish
Drag to orbit · scroll to zoom
$frame
$hardware
This definition leaves
$frame and $hardware
open, and a look line fills them. Every combination is one body — same
geometry, same selector, same sheets — so the block below rewrites itself as you pick.
Only materials are slottable: a size would have to agree with the plan, so it stays on
the entity.
Generated views
The body and its drawing evidence
The deterministic renders check the body's footprint, structure and depth. Geometry, material and the selected finish stay unchanged.
Paste this
Every part: the 2 materialdefs the body resolves to, then the definition. Copying the lookdef alone still compiles and still validates — it just renders grey.
{"t":"materialdef","id":"pack-envelope-stone","of":"stone","value":80,"accent":"#c7bfae","body":{"roughness":0.78}}
{"t":"materialdef","id":"pack-envelope-zinc","of":"steel","value":20,"accent":"#3d4347","body":{"roughness":0.38,"metalness":0.72}}
{"t":"lookdef","id":"folded-zinc-parapet-coping","name":"Folded zinc parapet coping","for":"asset:parapet-coping","desc":"Warm masonry parapet sample capped by folded dark zinc with two pronounced drip edges.","slots":{"frame":"pack-envelope-stone","hardware":"pack-envelope-zinc"},"note":"Natural box is 2.4 × 0.65 × 0.45; the cap overhangs both faces and its low drip edges make the weathering layer visible from front and rear.","body":{"type":"Group","children":[{"type":"Mesh","material":"$frame","geometry":{"type":"RoundedBoxGeometry","width":2.4,"height":0.54,"depth":0.42,"radius":0.025,"segments":3},"position":[0,0.27,0]},{"type":"Mesh","material":"$hardware","geometry":{"type":"RoundedBoxGeometry","width":2.48,"height":0.09,"depth":0.52,"radius":0.018,"segments":3},"position":[0,0.605,0],"rotation":[0,0,0.012]},{"type":"bimtex:Run","count":2,"from":[0,0,-0.255],"to":[0,0,0.255],"children":[{"type":"Mesh","material":"$hardware","geometry":{"type":"RoundedBoxGeometry","width":2.48,"height":0.12,"depth":0.035,"radius":0.008,"segments":3},"position":[0,0.55,0]}]}]},"preview":{"projection":"perspective","azimuth":38,"elevation":20,"fov":34,"margin":1.03}}Or take the whole pack, which brings every entry and every material at once:
cat packs/envelope.ndjson model.ndjson > dressed.ndjson
